High Filtration EfficiencyThe Festo LFMB-D-MINI-A boasts a filtration efficiency of 99.99%, ensuring that your compressed air system is free from contaminants and impurities, which is crucial for maintaining the quality of your pneumatic tools and systems.
2
Automatic Condensate DrainEquipped with a fully automatic condensate drain, this filter eliminates the need for manual intervention, reducing downtime and increasing overall system efficiency.
3
Robust ConstructionBuilt with durable materials, including a die-cast zinc housing and borosilicate fiber filter, the LFMB-D-MINI-A is designed to withstand the rigors of industrial environments, ensuring long-lasting performance.
4
Operational FlexibilityThe filter operates within a pressure range of 2 to 12 bar, making it versatile for various pneumatic applications. It also supports compressed air and inert gases, as per ISO 8573-1:2010 standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Series
D
Size
Mini
Structural design
Fiber filter
Grade of filtration
1μm
Condensate drain
Fully automatic
Symbol
00991520
5
Easy InstallationThe LFMB-D-MINI-A is designed for easy installation, whether in-line or with accessories. Its compact size and standardized connections (G1/4 ports) make it simple to integrate into your existing pneumatic setup.
Operating pressure
2bar 12bar
Operating medium
Compressed air as per ISO 8573-1:2010 [6:8:4] Inert gas
Air quality class at the output
Compressed air as per ISO 8573-1:2010 [5:7:3] Inert gas
Filter efficiency
99.99%
Max. condensate volume
22ml
Bowl guard
Metal bowl guard
Corrosion resistance class (CRC)
2 - Moderate corrosion stress
LABS (PWIS) conformity
VDMA24364-B1/B2-L
Temperature of medium
1.5°C 60°C
Ambient temperature
-10°C 60°C
Storage temperature
-10°C 60°C
Residual oil content
0.5mg/m3
Type of mounting
Optionally: Line installation With accessories
Mounting position
Vertical +/- 5°
Pneumatic connection 1
Sub-base
Pneumatic connection 2
Sub-base
Housing material
Die-cast zinc
Compressed air filter material
Borosilicate fiber
Material of bowl
PC
Note on materials
RoHS-compliant
Manufacturer ID
192572
