High Precision and ReliabilityThe Festo ess-60-eu ensures precise movement and reliable operation, minimizing downtime and maximizing productivity.
2
Easy IntegrationDesigned for seamless integration, the ess-60-eu simplifies your automation processes, reducing setup time and complexity.
3
Efficient OperationWith its optimized motor and drive system, the ess-60-eu operates efficiently, reducing energy consumption and costs.
4
Versatile ApplicationsSuitable for a wide range of industrial applications, including automotive, electronics, and food processing, the ess-60-eu adapts to your specific needs.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Min. workpiece radius
120mm
Nominal width
6mm
Suction cup diameter
60mm
Suction cup volume
19.77cm3
Connection position
Top
Mounting position
Any
Quality and AffordabilityCombining high-quality components with an unbeatable price, the Festo ess-60-eu offers exceptional value for your investment, ensuring long-term cost savings and performance.
6
Feature### Additional Information
7
- Product RangeThe Festo ess-60-eu is part of the Blue Star Core Products, which include over 2,200 items designed to handle 80% of all automation tasks.
Symbol
00991485
Classification of suction cup holder
Size 5
Suction cup shape
Round, extra-deep
Operating pressure
-13.775psi 0psi
Nominal operating pressure
-10.15psi
Operating medium
Atmospheric air based on ISO 8573-1:2010 [7:-:-]
Corrosion resistance class (CRC)
1 - Low corrosion stress
LABS (PWIS) conformity
VDMA24364 zone III
For use in the food industry
See supplementary material information
Ambient temperature
-20°C 60°C
Holding force at nominal operating pressure
162.5N
Lateral force at nominal operating pressure
134N
Product weight
48g
Type of mounting
Via vacuum connection
Vacuum connection
M10
Color
Blue
Shore hardness
60 +/- 5
Material of screwed plug
Wrought aluminum alloy, nickel-plated Steel, nickel-plated Steel, galvanized and chrome-plated
