High-Quality ConstructionThe Festo AEVUZ-100-15-A-P-A is built with high-alloy steel for the piston rod and wrought aluminum alloy for the cylinder barrel, ensuring durability and reliability in demanding applications.
2
Elastic CushioningEquipped with elastic cushioning rings/plates at both ends, this cylinder provides smooth operation and reduces wear and tear on the moving parts, extending its lifespan.
3
Flexible Mounting OptionsThe AEVUZ-100-15-A-P-A offers flexible mounting options, including through-hole and accessory mounting, allowing for easy integration into various systems.
4
Moderate Corrosion ResistanceWith a corrosion resistance class of CRC 2, this cylinder is suitable for applications where moderate corrosion stress is expected, ensuring consistent performance over time.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
15mm
Piston diameter
100 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting Pulling
Piston rod end
External thread
5
Operational FlexibilityThe cylinder operates at pressures ranging from 0.8 to 10 bar, making it versatile for a wide range of pneumatic applications, from light to heavy-duty operations.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991204
Variants
Piston rod at one end
Operating pressure
11.6psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
