Reliable OperationThe Festo AEVUZ-12-10-A-P-A compact cylinder ensures consistent and reliable operation, making it a trusted choice for industrial applications.
2
Durable ConstructionMade from high-alloy stainless steel, this cylinder offers exceptional durability and resistance to corrosion, ensuring long-lasting performance.
3
Efficient DesignWith a compact design and optimized stroke length, the AEVUZ-12-10-A-P-A reduces energy consumption and enhances operational efficiency.
4
Elastic CushioningThe elastic cushioning rings/plates at both ends provide smooth operation and reduce wear and tear on the cylinder, extending its lifespan.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
10mm
Piston diameter
12 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting Pulling
Piston rod end
External thread
Versatile ApplicationSuitable for a wide range of industrial applications, including manufacturing, automation, and robotics, the AEVUZ-12-10-A-P-A is a versatile and reliable solution.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991204
Variants
Piston rod at one end
Operating pressure
21.75psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
