advu-16-10-a-p-a

Name: advu-16-10-a-p-a
Brand: FESTO
SKU: advu-16-10-a-p-a

Festo ADVU-16-10-A-P-A compact cylinder features a 10mm stroke, 16mm piston diameter, and elastic cushioning rings for reliable performance. Suitable for double-acting applications with compressed air.

Product Modeladvu-16-10-a-p-a

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
High Precision OperationThe Festo ADVU-16-10-A-P-A compact cylinder ensures precise movement with its 10mm stroke and 16mm piston diameter, making it ideal for applications requiring high accuracy.
2
Elastic CushioningEquipped with elastic cushioning rings at both ends, this cylinder provides smooth and controlled motion, reducing wear and tear on the system.
3
Versatile Mounting OptionsThe cylinder offers optional mounting positions, allowing for flexible integration into various mechanical systems.
4
Double-Acting CapabilityDesigned for double-acting operations, the ADVU-16-10-A-P-A can handle both advancing and returning strokes efficiently, enhancing system performance.
5

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Stroke

10mm

Piston diameter

16 mm

Cushioning

Elastic cushioning rings/pads at both ends

Mounting position

Any

Mode of operation

Double-acting

Piston rod end

External thread

Compressed Air CompatibilityOperating with compressed air to ISO 8573-1:2010 [7:4:4] standards, this cylinder ensures reliable performance in a wide range of pneumatic applications.

Corrosion Resistance and DurabilityFeaturing a corrosion resistance class of CRC 2 and made from high-quality materials like high-alloy stainless steel and wrought aluminium alloy, the ADVU-16-10-A-P-A is built to last in demanding environments.

Position Detection and ControlEquipped with proximity switch for position detection, this cylinder allows for precise control and monitoring of its movement, enhancing overall system reliability.

Operating Pressure RangeThe cylinder operates within a pressure range of 0.12 MPa to 1 MPa (1.2 bar to 10 bar), making it suitable for a variety of pneumatic system requirements.

Impact Energy and ForceWith an impact energy of 0.1 J and theoretical forces of 90 N (return stroke) and 121 N (advance stroke) at 0.6 MPa, this cylinder provides consistent and controlled force delivery.

Maintenance and SupportFesto’s comprehensive support and maintenance options ensure that you have the necessary tools and expertise to keep your systems running smoothly and efficiently.

Position sensing

For proximity sensor

Symbol

00991217

Variants

Piston rod at one end

Operating pressure

17.4psi 145psi

Operating medium

Compressed air as per ISO 8573-1:2010 [7:4:4]

Information on operating and pilot media

Operation with oil lubrication possible (required for further use)

Corrosion resistance class (CRC)

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Ambient temperature

-20°C 80°C

Impact energy in the end positions

0.1J

Theoretical force at 6 bar, retracting

90N

Theoretical force at 6 bar, advancing

121N

Moving mass at 0 mm stroke

12g

Additional moving mass per 10 mm stroke

Basic weight with 0 mm stroke

89g

Additional weight per 10 mm stroke

15g

Type of mounting

Optionally: With through-hole With accessories

Pneumatic connection

Flange screws material

High-alloy stainless steel

Cover material

Wrought aluminum alloy

Material of dynamic seals

NBR TPE-U(PU)

Piston rod material

High-alloy stainless steel

Material of cylinder barrel

Wrought aluminum alloy

Manufacturer ID

156594
