aevuz-50- -p-a-s6

Name: aevuz-50- -p-a-s6
Brand: FESTO
SKU: aevuz-50- -p-a-s6

The Festo AEVUZ-50-P-A-S6 compact cylinder offers high performance and flexibility with its double-acting, non-rotating design and square piston rod. Ideal for automation tasks requiring precise control and durability.

Product Modelaevuz-50- -p-a-s6

Material Number156476

Product ID3651

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
High Performance and DurabilityThe AEVUZ-50-P-A-S6 is engineered to provide exceptional performance and durability, making it suitable for demanding automation tasks. Its robust construction ensures reliable operation under various conditions.
2
Flexible CushioningEquipped with flexible cushioning rings/plates at both ends, this cylinder minimizes wear and tear, extending its lifespan. This feature also enhances the overall efficiency of the system by reducing shock loads.
3
Proximity SensingThe AEVUZ-50-P-A-S6 features proximity sensing, allowing for precise control and monitoring of the piston position. This capability is crucial in applications requiring accurate positioning and feedback.
4
Versatile Mounting OptionsThis compact cylinder offers versatile mounting options via through-holes, female threads, and accessories. This flexibility makes it easy to integrate into various automation systems, ensuring a seamless fit.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Stroke

1mm 25mm

Piston diameter

50 mm

Cushioning

Elastic cushioning rings/pads at both ends

Mounting position

Any

Mode of operation

Single-acting Pulling

Piston rod end

Internal thread

Compliance with International StandardsThe AEVUZ-50-P-A-S6 conforms to ISO 1179-1 and ISO 228-1 standards, ensuring compatibility with a wide range of industrial applications. This compliance guarantees that the product meets the highest quality and safety standards.

Operating Pressure RangeThe cylinder operates within a wide pressure range, from 1.2 to 10 bar, depending on the piston diameter. This versatility allows it to be used in various pneumatic systems, catering to different load requirements.

Heat ResistanceThe AEVUZ-50-P-A-S6 is heat-resistant up to 120°C, making it suitable for applications in environments with moderate to high temperatures. This feature extends its operational range and reliability in diverse industrial settings.

Corrosion ResistanceWith a corrosion resistance class of 2 according to Festo standard FN 940070, the AEVUZ-50-P-A-S6 is designed to withstand moderate corrosion stress. This ensures its longevity in applications where exposure to moisture or chemicals is a concern.

Operating Medium CompatibilityThe cylinder can operate with both lubricated and unlubricated compressed air, providing flexibility in system design and maintenance. This compatibility ensures that the product can be easily integrated into existing or new pneumatic systems.

Compact DesignThe AEVUZ-50-P-A-S6 features a compact design, making it ideal for space-constrained applications. Its compact size allows for efficient use of space, enhancing the overall productivity of the automation system.

Position sensing

For proximity sensor

Symbol

00991204

Variants

Heat-resistant seals max. 120°C

Operating pressure

11.6psi 145psi

Operating medium

Compressed air as per ISO 8573-1:2010 [7:4:4]

Information on operating and pilot media

Operation with oil lubrication possible (required for further use)

Corrosion resistance class (CRC)

2 - Moderate corrosion stress

LABS (PWIS) conformity

VDMA24364-B1/B2-L

Ambient temperature

0°C 120°C

Impact energy in the end positions

0.64J

Theoretical force at 6 bar, advancing

999N

Moving mass at 0 mm stroke

112g

Additional moving mass per 10 mm stroke

16g

Basic weight with 0 mm stroke

560g

Additional weight per 10 mm stroke

72g

Type of mounting

Optionally: With through-hole With accessories

Pneumatic connection

G1/8

Flange screws material

Steel, galvanized

Cover material

Wrought aluminum alloy

Material of dynamic seals

FPM

Piston rod material

High-alloy steel

Material of cylinder barrel

Wrought aluminum alloy

Manufacturer ID

156476
