Festo AEVULQ-100-A-P-A-S2: Double-acting, non-rotating compact cylinder with a square piston rod, heat-resistant up to 120°C, suitable for various industrial applications.
Product Modelaevulq-100- -a-p-a-s2
Material Number156379
Product ID3631
Stock on Request
Last updated: 8/29/2026
Key Features
1
Heat ResistanceThe Festo AEVULQ-100-A-P-A-S2 is heat-resistant up to 120°C, making it suitable for high-temperature applications without compromising performance.
2
Non-Rotating DesignThis compact cylinder features a non-rotating design with a square piston rod, ensuring precise and reliable operation in demanding environments.
3
Double-Acting CapabilityDesigned for double-acting operations, the AEVULQ-100-A-P-A-S2 can handle both pushing and pulling forces, enhancing versatility in industrial applications.
4
Compact and LightweightThe compact design and lightweight construction of the AEVULQ-100-A-P-A-S2 make it easy to integrate into various systems, reducing overall system weight and complexity.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
1mm 25mm
Piston diameter
100 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting
Piston rod end
External thread
5
High-Quality MaterialsConstructed with high-quality materials, this compact cylinder ensures durability and longevity, minimizing maintenance requirements and extending the lifespan of the product.
6
Compliance with StandardsThe Festo AEVULQ-100-A-P-A-S2 conforms to ISO 1179-1 and ISO 228-1 standards, ensuring compatibility with a wide range of industrial systems and applications.
7
Flexible Mounting OptionsAvailable with flexible mounting options via through-holes, female threads, and accessories, the AEVULQ-100-A-P-A-S2 can be easily integrated into various mounting configurations.
8
Operational FlexibilitySuitable for use with filtered compressed air, lubricated or unlubricated, the AEVULQ-100-A-P-A-S2 offers operational flexibility in different working conditions.
9
Proximity Sensing CapabilityEquipped with proximity sensing capabilities, this compact cylinder ensures accurate positioning and control in precision applications.
10
ATEX ComplianceSpecified types of the AEVULQ-100-A-P-A-S2 are ATEX compliant, making it suitable for use in hazardous environments where explosive atmospheres may occur.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991202
Variants
Through piston rod
Protection against torsion/guide
Square piston rod
Operating pressure
14.5psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
