The Festo AEVULQ-25- -P-A is a compact, single-acting pneumatic cylinder with a square piston rod for anti-rotation protection and proximity sensing for precise positioning.
Product Modelaevulq-25- -p-a
Material Number156323
Product ID3597
Stock on Request
Last updated: 8/29/2026
Key Features
1
Compact DesignDescription: The Festo AEVULQ-25- -P-A is designed to be compact, requiring 50% less space than comparable standard cylinders, making it ideal for space-constrained applications.
2
Anti-Rotation ProtectionDescription: Equipped with a square piston rod, this cylinder is secured against rotation, ensuring stability and reliability in various operational conditions.
3
Proximity SensingDescription: The AEVULQ-25- -P-A features proximity sensing, allowing for precise positioning and control, which is crucial in applications requiring high accuracy.
4
Reliable CushioningDescription: The cylinder is equipped with flexible cushioning rings/plates at both ends, providing reliable cushioning and reducing wear and tear, ensuring longer lifespan.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
1mm 25mm
Piston diameter
25 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Pushing Single-acting
Piston rod end
Internal thread
5
Versatile ApplicationsDescription: The Festo AEVULQ-25- -P-A is suitable for a wide range of applications, including those in potentially explosive atmospheres, thanks to its compliance with the ATEX directive.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991729
Variants
Piston rod at one end
Protection against torsion/guide
Square piston rod
Operating pressure
14.5psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
