Precision and ReliabilityThe Festo AEVU-25-A-P-A-S20 is engineered to provide precise movements and reliable operation, making it a top choice for demanding industrial applications.
2
Flexible CushioningEquipped with elastic cushioning rings/plates at both ends, this cylinder ensures smooth operation and reduces wear and tear, extending its lifespan.
3
Proximity SensingFeaturing proximity sensing capabilities, the AEVU-25-A-P-A-S20 allows for precise position detection, enhancing control and accuracy in your applications.
4
Wide Operating Pressure RangeThis cylinder operates within a wide pressure range of 0.12 MPa to 1 MPa (1.2 bar to 10 bar), making it versatile for various pneumatic systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
1mm 25mm
Piston diameter
25 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting
Piston rod end
External thread
5
Durable ConstructionBuilt with high-quality materials, including a high-alloy stainless steel piston rod and a wrought aluminum alloy cylinder barrel, the AEVU-25-A-P-A-S20 is designed for durability and longevity.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991203
Variants
Through, hollow piston rod
Operating pressure
17.4psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
