Elastic Cushioning Rings/PlatesThe AEVU-25-A-P-A-S2 features elastic cushioning rings/plates at both ends, ensuring smooth and controlled movement, reducing wear and tear on the cylinder.
2
Double-Acting OperationThis compact cylinder is designed for double-acting operation, allowing for both extension and retraction strokes, enhancing versatility in automation applications.
3
Durable ConstructionBuilt with high-quality materials, including a wrought aluminum alloy cover and a high-alloy stainless steel piston rod, the AEVU-25-A-P-A-S2 offers durability and longevity.
4
Flexible Mounting OptionsThe cylinder can be mounted via through-holes or accessories, providing flexibility in installation and integration into various automation systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
1mm 25mm
Piston diameter
25 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting
Piston rod end
External thread
5
Corrosion ResistanceWith a corrosion resistance class of CRC 2, the AEVU-25-A-P-A-S2 is designed to withstand moderate corrosion stress, ensuring reliable performance in industrial environments.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991202
Variants
Through piston rod
Operating pressure
17.4psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
