Festo ADVU-63- -P-A-S2: Double-acting compact cylinder with 63mm piston diameter, 1-300mm stroke, elastic cushioning, and proximity sensing. Perfect for industrial applications.
Product Modelaevu-63- -p-a-s2
Material Number156237
Product ID3542
Stock on Request
Last updated: 8/29/2026
Key Features
1
Versatile Stroke LengthThe Festo ADVU-63- -P-A-S2 offers a versatile stroke length ranging from 1 mm to 300 mm, making it suitable for a wide range of applications.
2
Elastic CushioningEquipped with elastic cushioning rings/plates at both ends, this cylinder ensures smooth operation and reduces wear and tear.
3
Proximity SensingPosition detection via proximity switch allows for precise control and monitoring of the cylinder's position, enhancing overall system accuracy.
4
High-Pressure OperationDesigned to operate under pressures of 0.08 MPa to 1 MPa (0.8 bar to 10 bar), this cylinder is robust and reliable in high-pressure environments.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Stroke
1mm 25mm
Piston diameter
63 mm
Cushioning
Elastic cushioning rings/pads at both ends
Mounting position
Any
Mode of operation
Single-acting
Piston rod end
Internal thread
Corrosion ResistanceWith a corrosion resistance class of CRC 2, the Festo ADVU-63- -P-A-S2 can withstand moderate corrosion stress, ensuring durability in various industrial settings.
Structural design
Piston Piston rod
Position sensing
For proximity sensor
Symbol
00991202
Variants
Through piston rod
Operating pressure
11.6psi 145psi
Operating medium
Compressed air as per ISO 8573-1:2010 [7:4:4]
Information on operating and pilot media
Operation with oil lubrication possible (required for further use)
