Reliability and DurabilityThe Festo SMTO-4U-NS-S-LED-24 is built to last, ensuring consistent performance in demanding industrial environments. Its robust design and high-quality materials guarantee long-lasting reliability.
2
Precise DetectionEquipped with advanced detection technology, this proximity sensor provides accurate and reliable results, minimizing errors and ensuring efficient operation.
3
Easy IntegrationDesigned for seamless integration, the SMTO-4U-NS-S-LED-24 is easy to set up and use, reducing installation time and complexity. Its compact size makes it perfect for a variety of applications.
4
Switching Status IndicationThe sensor features a yellow LED for switching status indication, providing clear visual feedback and enhancing user experience. This feature ensures that the sensor's status is always easily visible.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Design
Round
Based on norm
EN 60947-5-2
Symbol
00991150
Certification
RCM compliance mark
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
UKCA marking (see declaration of conformity)
To UK instructions for EMC To UK RoHS instructions
5
IP67 Degree of ProtectionWith an IP67 rating, the SMTO-4U-NS-S-LED-24 is protected against dust and water, making it suitable for harsh environments. This level of protection ensures the sensor can operate reliably in challenging conditions.
Note on materials
RoHS-compliant
Measured variable
Position
Measuring principle
Magneto-inductive
Ambient temperature
-25°C 70°C
Repetition accuracy
0.2mm
Switching output
NPN
Switching element function
N/O contact
On time
0.5ms
Switch-off time
0.5ms
Max. output current
200mA
Max. switching capacity DC
6W
Voltage drop
2V
Inductive protective circuit
Installed
Minimum load current
0.1mA
Residual current
0.01mA
Short-circuit protection
Pulsed
Overload protection
Available
DC operating voltage range
10V 30V
Residual ripple
10 %
Reverse polarity protection
for all electrical connections
Electrical connection 1, connection type
Plug
Electrical connection 1, connection technology
M8x1 A-coded as per EN 61076-2-104
Electrical connection 1, number of pins/wires
3
Electrical connection 1, type of mounting
Screw-type lock
Electrical connection for input 1, connection pattern
