The Festo SMTO-1-PS-S-LED-24-C proximity sensor is designed for precise detection in industrial applications, ensuring reliable operation and efficient automation.
Product Modelsmto-1-ps-s-led-24-c
Material Number151685
Product ID2802
Stock on Request
Last updated: 8/29/2026
Key Features
1
Precise DetectionThe SMTO-1-PS-S-LED-24-C features advanced detection technology, providing accurate and reliable measurements in various industrial environments.
2
LED IndicationEquipped with an LED indicator, this sensor offers visual feedback, making it easier to monitor its status and performance.
3
Compact DesignThe compact design of the SMTO-1-PS-S-LED-24-C makes it ideal for integration into complex automation systems without occupying excessive space.
4
High ReliabilityBuilt with high-quality components, this proximity sensor ensures consistent performance and longevity, reducing the need for frequent replacements.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Design
Block design
Based on norm
EN 60947-5-2
Symbol
00991153
Certification
RCM compliance mark
CE marking (see declaration of conformity)
As per EU EMC directive As per EU RoHS directive
UKCA marking (see declaration of conformity)
To UK instructions for EMC To UK RoHS instructions
Easy InstallationThe SMTO-1-PS-S-LED-24-C is designed for straightforward installation, minimizing downtime and ensuring quick setup in your industrial automation projects.
Note on materials
RoHS-compliant
Measured variable
Position
Measuring principle
Magneto-inductive
Ambient temperature
-25°C 70°C
Repetition accuracy
0.2mm
Switching output
PNP
Switching element function
N/O contact
Hysteresis
0.1mm 1.5mm
On time
1ms
Switch-off time
1ms
Max. switching frequency
1000Hz
Max. output current
200mA
Max. switching capacity DC
6W
Voltage drop
3V
Inductive protective circuit
Adapted to MZ, MY and ME coils
Residual current
0.01mA
Short-circuit protection
Pulsed
Overload protection
Available
DC operating voltage range
10V 30V
Residual ripple
10 %
Reverse polarity protection
for all electrical connections
Electrical connection 1, connection type
Plug
Electrical connection 1, connection technology
M8x1 A-coded as per EN 61076-2-104
Electrical connection 1, number of pins/wires
3
Electrical connection for input 1, connection pattern
