WAGO 713-1410/116-000/997-408 connector: High-quality, reliable, and easy to install with spring pressure technology.
Product Model713-1410/116-000/997-408
Product ID111083
Stock on Request
Last updated: 8/29/2026
Key Features
1
FeatureHigh-quality and reliable electrical connections
2
FeatureInnovative spring pressure connection technology for easy installation
3
FeatureVersatile application in industrial and residential settings
4
FeatureFree shipping available
5
Feature24/7 customer service support
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Safety information
TheMCS MULTI CONNECTION SYSTEMincludes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load.When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure header pins, which can be touched, are not live when unmated.
Variants:
Other pole numbers
Total number of potentials
20
Number of connection types
1
Number of levels
2
Pin spacing
3.5 mm / 0.138 inches
Width
43.1 mm / 1.697 inches
Height
15.9 mm / 0.626 inches
Height from the surface
13.5 mm / 0.531 inches
Depth
13.3 mm / 0.524 inches
Solder pin length
2.4mm
Solder pin dimensions
0.8 x 0.8 mm
Plated through-hole diameter (THR)
1.3(+0.1)mm
Reel diameter of tape-and-reel packaging
330mm
Tape width
72mm
Variable coding
Yes
Anti-rotation protection
Yes
Contact type (pluggable connector)
Male connector/plug
Connector (connection type)
for PCB
Mismating protection
Yes
Plugging without loss of pin spacing
No
Mating direction to the PCB
90°
Locking of plug-in connection
Locking lever
PCB contact
THR
Solder pin arrangement
over the entire male connector (in-line)
Number of solder pins per potential
1
Note (material data)
Information on material specifications can be found here
