The WAGO 289-722 is a 25-pole interface module with a D-subminiature male connector and double-deck PCB terminal blocks, suitable for industrial use.
Product Model289-722
Product ID109906
Stock on Request
Last updated: 8/29/2026
Key Features
1
Feature25-pole D-subminiature male connector for reliable connections
2
FeatureDouble-deck PCB terminal blocks for efficient wiring
3
FeatureDesigned for mounting in a carrier for secure installation
4
FeatureSuitable for solder connections
5
FeatureHigh-quality construction from WAGO Corporation for durability and performance
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Note
One solder terminal per pole is available for testing and patching (except for shield contact).
Operating voltage
≤ 0 VAC; ≤ 0 VDC
Nominal current
2A
Contact resistance (max.)
30 mΩ
Specialty functions
With solder pin
Rated voltage
50V
Pollution degree
2
Protection type
IP00;Notice!Live parts can be easily touched! Protection against direct contact must be provided by the equipment manufacturer, e.g., using a WAGO 709 Series Cover (see 鈥淎ccessories or a similar cover. The installation guidelines must be observed for each individual application.
