pun-h-5/16-bl-1000-ha

Name: pun-h-5/16-bl-1000-ha
Brand: FESTO
SKU: pun-h-5/16-bl-1000-ha

Festo's Pneumatic Cylinder Drive offers precision and durability for efficient automation in various industrial applications. Ideal for linear and swivel movements, these drives ensure reliable performance and long service life.

Product Modelpun-h-5/16-bl-1000-ha

Material Number568022

Product ID109517

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
Precision EngineeringFesto's pneumatic cylinder drives are engineered to provide precise linear and swivel movements, ensuring accurate control in industrial automation.
2
DurabilityConstructed with high-quality materials, these drives offer a long service life and withstand harsh industrial environments.
3
VersatilityAvailable in various configurations, including piston rod cylinders, rodless cylinders, and swivel cylinders, to meet diverse application needs.
4
EfficiencyDesigned for high-performance operation, these drives minimize energy consumption and maximize productivity in industrial processes.
5

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

External-Ã˜ inches

5/16

Bending radius relevant for flow rate

36.881mm

Min. bending radius

19.812mm

Application note

TPE-U Ether based

Tubing characteristics

Suitable for energy chains

Temperature-dependent operating pressure

-0.993bar 9.997bar

Ease of IntegrationWith standardized dimensions and mounting interfaces, Festo's pneumatic cylinder drives are easy to integrate into existing automation systems, reducing setup time and complexity.

Information on operating pressure

Water: temperature-dependent operating pressure, see diagram, max. 0.3 MPa at 0 - 60 °C

Operating medium

Compressed air as per ISO 8573-1:2010 [7:-:-] Water (liquid, ice-free)

Material fire test

UL94 HB

LABS (PWIS) conformity

VDMA24364-B2-L

Suitability for the production of Li-ion batteries

Metals with more than 1% by mass of copper, zinc or nickel are excluded from use.The exceptions are nickel in steel, chemically nickel-plated surfaces, circuit boards, cables, electrical plug connectors and coils

Cleanroom class

Statically installed element, no meaningful evaluation possible according to ISO 14644-1

For use in the food industry

See supplementary material information

Ambient temperature

-35°C 63°C

Product weight by length

0.31kg/m

Pneumatic connection

For plug connection outside diameter 5/16;

Color

Blue

Shore hardness

D 52 +/-3

Note on materials

RoHS-compliant

Material of pneumatic tubing

TPE-U(PU)

Manufacturer ID

568022
