Allen Bradley 140G-HC6C3-C32 Molded Case Circuit Breaker: 125A, 70kA @ 415V, thermal magnetic protection, ideal for global applications.
Product Model140G-HC6C3-C32
Product ID109182
Stock on Request
Last updated: 8/29/2026
Key Features
1
1. High Interrupting CapacityThe 140G-HC6C3-C32 boasts a high interrupting capacity of 70kA at 415V, ensuring reliable protection against short circuits.
2
2. Thermal Magnetic ProtectionEquipped with thermal magnetic protection, this circuit breaker provides comprehensive protection against both thermal and magnetic faults.
3
3. Global Application ApprovalCertified for global use with approvals from UL, CSA, CCC, and IEC, making it suitable for a wide range of applications worldwide.
4
4. Customizable Trip UnitsOffers customizable trip units to fit various panel configurations, allowing for greater flexibility in system design.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Adjustment Type
Fixed/TM Current Limiting
IEC Breaking Capacity
70kA @ 415V
Protection
Thermal Magnetic
Rating/Size
125 A, H-Frame
Trip Unit Rating
32 A
UL Interrupting Rating
65kA @ 480V
5. Compact DesignDesigned in a compact frame, this circuit breaker is ideal for space-constrained installations while maintaining high performance standards.
