Compact, efficient 15W switched mode power supply with wide input voltage range, high efficiency, and built-in redundancy for continuous power supply in industrial automation.
Product Model1606-XLP15E
Product ID107900
Stock on Request
Last updated: 8/29/2026
Key Features
1
1. Compact DesignThe Allen Bradley 1606-XLP15E features a compact design, enabling space savings in the panel. Its dimensions are 75 mm in height, 91 mm in depth, and 22.5 mm in width, making it perfect for installations where space is limited.
2
2. Efficient PerformanceDesigned for efficient performance, the 1606-XLP15E offers up to 85.1% efficiency, resulting in less heat waste and improved overall system reliability. This efficiency also translates to longer component lifespan and reduced maintenance needs.
3
3. Wide Input Voltage RangeThis power supply can handle single and multi-phase AC and DC input voltages, with an operational range of 85 to 264V AC. This versatility makes it suitable for various industrial environments and applications.
4
4. Built-in RedundancyThe 1606-XLP15E includes built-in redundancy modules, ensuring continuous power supply to the load. This feature is crucial in mission-critical applications where downtime is not acceptable, providing reliability and ensuring system uptime.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Height
75 mm
Depth
91 mm
Direct mounting possible
No
Width
22.5 mm
Degree of protection (IP)
IP20
Type of electric connection
Screw connection
5
5. Stable Output VoltageThe power supply features an output voltage stabilized to 85V DC, with a ripple and noise level of up to 50 mV. This stability ensures consistent performance and reliability, making it suitable for applications requiring precise voltage control.
Shock
30 G, 6 ms 20G, 11 ms
Special functions
No special function
MTBF
4369000 hr @ 40 °C, SN 29500
Wall mounting possible
Yes
Degree of protection (NEMA)
Other
Vibration
2 g
Secondary voltage adjustable
Yes
Power output
15 W
Voltage type of supply voltage
AC/DC
Rated supply voltage at DC
85 V
Efficiency, typ
85.1 %
Adjustment range
24 V
Operational range
85...264V AC
Rated output current
0.54 to 0.63 A
Phases
1-phase
Sub group
Compact family
Hold-up time
>47 ms @ 100V AC
Input voltage
100â¦240V AC
Special family function
No power boost
Rated input current
<0.28A @ 100V AC
Special feature
-
Output voltage stabilized
Yes
Rail mounting possible
Yes
Stabilized
Yes
Ripple and noise, max
50 mV
Operating temperature
-10 °C
Storage temperature
-40 °C
Relative humidity
5 to 95 %
Weight
0.152
Repairable
NOT_REPAIRABLE
Preferred Availability
true
Quick Turnaround
false
Dimension Height
2.896
Lead Time
5
Dimension Width
10.008
Dimension Length
12.802
Stock Status
STOCKED
Weight Unit
KG
Dimension Unit
CM
