150-C361NCD

Name: 150-C361NCD
Brand: ROCKWELL
SKU: 150-C361NCD

The Allen Bradley 150-C361NCD is a versatile smart motor controller suitable for 3-phase applications. It supports up to 600V and operates on a control voltage of 100-240V AC, making it a reliable choice for various industrial settings.

Product Model150-C361NCD

Product ID107483

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
1. Efficient ControlThe Allen Bradley 150-C361NCD provides precise control over motor operations, ensuring optimal performance and efficiency in your industrial applications.
2
2. High Voltage CapabilityWith a voltage rating of up to 600V, this smart motor controller is designed to handle demanding industrial environments, making it a robust choice for heavy-duty applications.
3
3. Wide Operating RangeOperating on a control voltage of 100-240V AC, the 150-C361NCD offers flexibility in various electrical configurations, ensuring compatibility with different systems.
4
4. Reliability and DurabilityBuilt with high-quality components, this smart motor controller is engineered for reliability and durability, minimizing downtime and maintenance costs.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Product Family

SMC-3

With display

Voltage type for actuating

AC/DC

Rated operating voltage Ue

200

Rated control supply voltage at AC 50 Hz

100

Rated control supply voltage at AC 60 Hz

100

5. Versatile ApplicationsSuitable for a wide range of industrial applications, including manufacturing, processing, and automation, the Allen Bradley 150-C361NCD is an essential component for any modern factory setup.

DV/DT protection

1000V/Î¼s for power circuit

Repetitive peak voltage

1600V per UL/CSA/NEMA for power circuit

Operating frequency

50/60 Hz per UL/CSA/NEMA for power circuit

Overvoltage category

III per IEC for side mount auxiliary contacts

Rated impulse voltage

6 kV for power circuit

Dielectric withstand

2500V AC per IEC for power circuit

Delta connected motor current

208...625A @ 500/575V AC, 3-phase

Insulation voltage

Rated 600V AC per UL/CSA/NEMA for power circuit

Rated operational voltage

250V AC/30V DC per UL/CSA/NEMA for Side mount auxiliary contacts

Rated control power during start with fan

200mA @ 120V AC/120mA @ 240V AC, 600mA @ 24V AC/DC

Input OFF-state current

<10 mA, <12 mA @ input off-state voltage (IN1, IN2) for control circuit

Short-circuit protection device list

Non-time delay Thermal magnetic circuit breaker High capacity time delay class CC/J/L

Number of contacts

TB-97, -98 (OVLD/Fault): 1 for auxiliary contacts

High capacity available fault current, max

69kA @ 600V, maximum current 600 A time delay Class J or Class L fuse for line connected motors

Type of current

TB-97, -98 (OVLD/Fault): AC/DC for auxiliary contacts

Conventional thermal current (Ith)

TB-97, -98 (OVLD/Fault): 1 A for auxiliary contacts

Type of control circuit

TB-97, -98 (OVLD/Fault): Electromagnetic relay for auxiliary contacts

Type of contacts

TB-97, -98 (OVLD/Fault): Normally Open (N.O.) for auxiliary contacts

Utilization category

TB-23, -24 (normal/up-to-speed), TB-33, -34 (normal/up-to-speed): C300/R150 per UL/CSA/NEMA for Side mount auxiliary contacts

Rated operational current, max

TB-97, -98 (OVLD/Fault): 0.6A @ 120V AC and 0.3A @ 240V AC for auxiliary contacts

Standard controller feature

Soft stop

Integrated motor overload protection

Yes

Short circuit protection device performance (SCPD) type

Type 1

Selectable overload trip class

Trip Class 10, 15, or 20

Selectable start times

2, 5, 10, 15, 20, 25, or 30 s

Input OFF-state voltage (IN1, IN2), max

40V AC @ 17V DC/12V AC for control circuit

Selectable current limit

150%, 250%, 350%, and 450% of full load current

Input ON-state voltage, during start (IN1, IN2)

85V AC @ 19.2V DC/19.2V AC minimum for control circuit

Input ON-state current (IN1, IN2)

9.8mA @ 120V AC/19.6mA @ 240V AC for control circuit, 7.3mA @ 24V AC/DC for control circuit

Degree of protection (IP)

IP2X

Weight

43.758

Shock

Opsal: 15 G

Width

290 mm (11.42 in)

Height

600 mm (23.62 in)

Cable size

0.2...2.5 mm2 (24...14 AWG) for control terminals

Vibration

Opsal: 1.0 G peak, 0.15 mm (0.006 in) displacement

Make

TB-97, -98 (OVLD/Fault): 432VA for auxiliary contacts

Break

TB-97, -98 (OVLD/Fault): 72VA for auxiliary contacts

Tightening torque

0.45...0.9 Nm (4.0...8.0 in-lb) for control terminals

Internal bypass

Yes

Function

Single direction

Selectable kick start - 450% FLA

0, 0.5, 1.0, or 1.5 s

Selectable initial torque

15%, 25%, 35%, and 65% of locked rotor torque

Selectable soft stop

Off, 100%, 200%, or 300% of the start time setting when wired

Mounting hole size

11.5 mm

Number of poles

Equipment is designed for 3-phase only for power circuit

Enclosure

Open type

Storage and transportation temperature

-25 Â°C

Rated surrounding temperature range without derating

-5 Â°C

Humidity

5...95% noncondensing

Operating temperature

Open: -5 to 50 Â°C (23 to 122 Â°F)

EMC emission levels

Radiated emission: Class A per IEC

EMC immunity levels

Surge transient: per EN/IEC 60947-4-2 per IEC

Altitude

2000 m

Pollution degree

Repairable

REPAIRABLE

Preferred Availability

false

Quick Turnaround

false

Dimension Height

70.79

Lead Time

Dimension Width

41.91

Dimension Length

40.589

Stock Status

NON_STOCKED

Weight Unit

Dimension Unit
