High-efficiency 24VDC power supply with 20A output, active PFC, and 20% power reserve. Suitable for various industrial applications.
Product Model1606-XLE480EP-D
Product ID106660
Stock on Request
Last updated: 8/29/2026
Key Features
1
1. High EfficiencyThe 1606-XLE480EP-D operates at an efficiency of up to 95.6%, minimizing energy waste and reducing operational costs.
2
2. Active Power Factor Correction (PFC)Ensures a power factor of 0.98, reducing harmonic distortion and improving overall system efficiency.
3
3. Wide Operational Temperature RangeDesigned to operate between -25°C and +60°C, making it suitable for applications in harsh environments.
4
4. 20% Power ReserveProvides a 20% power reserve, which can be used continuously up to +45°C, ensuring reliable operation even under heavy loads.
5
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Nominal value output voltage 1
24 V
Secondary voltage adjustable
Yes
Max. output current 1
20 A
Nominal value output current 1
20 A
Power output
480 W
Voltage type of supply voltage
AC/DC
5. DC OK Relay ContactIncludes a DC OK relay contact, providing a reliable indication of the power supply's status, ensuring safe operation and easy monitoring.
1st secondary output voltage
24 V
Rated supply voltage at AC 50 Hz
100 V
Rated supply voltage at AC 60 Hz
100 V
Rated supply voltage at DC
110 V
Power reserves
20 %
DC OK relay contact
Yes
Input inrush current limiter
Active
Power factor
0.98 typical
Output current range
20 to 17.1 A
External input fuse, min
B-10 A or C-10 A
Power losses
22.1 W typical
Derating
12 W/°C
Efficiency
95.6 % typical
Input inrush current
10 A/4.5 A
Output voltage stabilized
Yes
Rail mounting possible
Yes
Stabilized
Yes
Height
124 mm
Depth
127 mm
Direct mounting possible
No
Width
48 mm
Degree of protection (IP)
IP20
Type of electric connection
Screw connection
MTBF
590 kh (+40 °C, SN29500)
Wall mounting possible
Yes
Ripple and noise, max
50 mV
Operating temperature
-25 °C
Lifetime, min
94 kh (+40 °C)
Weight
0.893
Repairable
NOT_REPAIRABLE
Preferred Availability
false
Quick Turnaround
false
Dimension Height
6.35
Lead Time
5
Dimension Width
15.24
Dimension Length
15.24
Stock Status
NON_STOCKED
Weight Unit
KG
Dimension Unit
CM
