150-C60NCR

Name: 150-C60NCR
Brand: ROCKWELL
SKU: 150-C60NCR

The Allen-Bradley 150-C60NCR is a high-performance smart motor controller, providing 60A, 600V, 3-phase operation with a control voltage of 24V AC/DC. It is designed for various industrial applications, including compressors, chillers, pumps, conveyors, and crushers, ensuring efficient and reliable motor control.

Product Model150-C60NCR

Product ID106258

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
1. Efficient Motor ControlThe Allen-Bradley 150-C60NCR offers precise control over motor operations, ensuring optimal performance and energy efficiency in industrial applications.
2
2. Reliable DesignBuilt with robust components, this smart motor controller provides reliable operation even in demanding environments, minimizing downtime and maintenance.
3
3. Versatile ApplicationsSuitable for a wide range of applications such as compressors, chillers, pumps, conveyors, and crushers, making it a versatile solution for various industrial needs.
4
4. Easy SetupThe controller features easy and secure setup using DIP switches, allowing for quick installation and configuration without requiring extensive technical expertise.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

With display

Voltage type for actuating

AC/DC

Rated operating voltage Ue

200

Rated control supply voltage at AC 50 Hz

24 V

Rated control supply voltage at AC 60 Hz

24 V

Controller type

SMC-3

5. Advanced Protection FeaturesEquipped with built-in electronic motor overload protection and a hold-to-test/push-to-reset button, ensuring safe and secure operation of the motor.

1000V/Î¼s for power circuit

Repetitive peak voltage

1600V per UL/CSA/NEMA for power circuit

Operating frequency

50/60 Hz per UL/CSA/NEMA for power circuit

Overvoltage category

III per IEC for side mount auxiliary contacts

Rated impulse voltage

6 kV for power circuit

Dielectric withstand

2500V AC per IEC for power circuit

Insulation voltage

Rated 600V AC per UL/CSA/NEMA for power circuit

Rated operational voltage

250V AC/30V DC per UL/CSA/NEMA for Side mount auxiliary contacts

Input OFF-state current

<10 mA, <12 mA @ input off-state voltage (IN1, IN2) for control circuit

Short-circuit protection device list

Non-time delay Thermal magnetic circuit breaker High capacity time delay class CC/J/L

Number of contacts

TB-97, -98 (OVLD/Fault): 1 for auxiliary contacts

Type of current

TB-97, -98 (OVLD/Fault): AC/DC for auxiliary contacts

Conventional thermal current (Ith)

TB-97, -98 (OVLD/Fault): 1 A for auxiliary contacts

Type of control circuit

TB-97, -98 (OVLD/Fault): Electromagnetic relay for auxiliary contacts

Type of contacts

TB-97, -98 (OVLD/Fault): Normally Open (N.O.) for auxiliary contacts

Utilization category

TB-23, -24 (normal/up-to-speed), TB-33, -34 (normal/up-to-speed): C300/R150 per UL/CSA/NEMA for Side mount auxiliary contacts

Rated operational current, max

TB-97, -98 (OVLD/Fault): 0.6A @ 120V AC and 0.3A @ 240V AC for auxiliary contacts

Standard controller feature

Soft stop

Rated control supply voltage at DC

24 V

Integrated motor overload protection

Yes

Short circuit protection device performance (SCPD) type

Type 1

Selectable overload trip class

Trip Class 10, 15, or 20

Selectable start times

2, 5, 10, 15, 20, 25, or 30 s

Input OFF-state voltage (IN1, IN2), max

40V AC @ 17V DC/12V AC for control circuit

Selectable current limit

150%, 250%, 350%, and 450% of full load current

Input ON-state voltage, during start (IN1, IN2)

85V AC @ 19.2V DC/19.2V AC minimum for control circuit

Input ON-state current (IN1, IN2)

9.8mA @ 120V AC/19.6mA @ 240V AC for control circuit, 7.3mA @ 24V AC/DC for control circuit

Degree of protection (IP)

IP2X

Shock

Opsal: 15 G

Vibration

Opsal: 1.0 G peak, 0.15 mm (0.006 in) displacement

Make

TB-97, -98 (OVLD/Fault): 432VA for auxiliary contacts

Break

TB-97, -98 (OVLD/Fault): 72VA for auxiliary contacts

Internal bypass

Yes

Function

Single direction

Selectable kick start - 450% FLA

0, 0.5, 1.0, or 1.5 s

Selectable initial torque

15%, 25%, 35%, and 65% of locked rotor torque

Selectable soft stop

Off, 100%, 200%, or 300% of the start time setting when wired

Storage and transportation temperature

-25 Â°C

Rated surrounding temperature range without derating

-5 Â°C

Humidity

5...95% noncondensing

Operating temperature

Open: -5 to 50 Â°C (23 to 122 Â°F)

EMC emission levels

Radiated emission: Class A per IEC

EMC immunity levels

Surge transient: per EN/IEC 60947-4-2 per IEC

Altitude

2000 m

Pollution degree

Number of poles

Equipment is designed for 3-phase only for power circuit

Enclosure

Open type

Repairable

NOT_REPAIRABLE

Preferred Availability

false

Quick Turnaround

false

Dimension Height

18.999

Lead Time

Dimension Width

28.001

Dimension Length

25.499

Stock Status

STOCKED

Weight

3.4

Weight Unit

Dimension Unit
