1606-XLE480EP

Name: 1606-XLE480EP
Brand: ROCKWELL
SKU: 1606-XLE480EP

The Allen Bradley 1606-XLE480EP is a reliable, compact power supply offering 480W output, adjustable 24-28VDC, and a wide 100-240VAC input range. Perfect for industrial applications requiring high efficiency and stability.

Product Model1606-XLE480EP

Product ID105952

Stock on Request

Last updated: 8/29/2026

Quantity

Key Features

1
1. High Efficiency and Power ReserveThe 1606-XLE480EP boasts an efficiency of up to 95.6%, ensuring minimal energy loss and a 20% power reserve for continuous operation up to +45°C (113°F).
2
2. Wide Input Voltage RangeWith an input voltage range of 100-240VAC and 110-150VDC, this power supply is versatile and can handle various input conditions, making it suitable for global applications.
3
3. Compact DesignThe ultra-slim design of the 1606-XLE480EP makes it ideal for space-constrained environments, ensuring easy integration into your industrial setup.
4
4. Active Power Factor Correction (PFC)The active PFC feature ensures a high power factor of 0.98, reducing harmonic distortion and improving overall system efficiency.

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Nominal value output voltage 1

24 V

Secondary voltage adjustable

Yes

Max. output current 1

20 A

Nominal value output current 1

20 A

Power output

480 W

Voltage type of supply voltage

AC/DC

5. Reliability and DurabilityEquipped with an active inrush current limiter and a DC OK relay contact, this power supply provides reliable operation and protects against power surges and transients, ensuring continuous performance in harsh environments.

6. Easy Installation and ConfigurationThe 1606-XLE480EP features quick-connect spring-clamp terminals for easy cabinet wiring and a user-friendly design that simplifies installation and configuration processes.

7. Operational FlexibilityThe power supply offers adjustable output voltage from 24 to 28VDC, providing flexibility in meeting the specific voltage requirements of various industrial applications.

8. Safety FeaturesThe device includes a safe hiccup mode for overload protection, ensuring safe operation even under abnormal conditions. Additionally, it has a minimal inrush current surge, reducing the risk of electrical shock or damage to the system.

9. DIN Rail MountingDesigned for DIN rail mounting, the 1606-XLE480EP is easy to integrate into your existing industrial control systems, saving time and space.

10. Compliance with Global Standards- The power supply meets all global safety standards and is UL Listed, making it suitable for a wide range of industrial applications worldwide.

1st secondary output voltage

Rated supply voltage at AC 50 Hz

100 V

Rated supply voltage at AC 60 Hz

100 V

Rated supply voltage at DC

110 V

Power reserves

20 %

DC OK relay contact

Yes

Input inrush current limiter

Active

Power factor

0.98 typical

Output current range

20 to 17.1 A

External input fuse, min

B-10 A or C-10 A

Power losses

22.1 W typical

Derating

12 W/Â°C

Efficiency

95.6 % typical

Input inrush current

10 A/4.5 A

Output voltage stabilized

Yes

Rail mounting possible

Yes

Stabilized

Yes

Height

124 mm

Depth

127 mm

Direct mounting possible

Width

48 mm

Degree of protection (IP)

IP20

Type of electric connection

Screw connection

MTBF

590 kh (+40 Â°C, SN29500)

Wall mounting possible

Yes

Ripple and noise, max

50 mV

Operating temperature

-25 Â°C

Lifetime, min

94 kh (+40 Â°C)

Weight

0.896

Repairable

NOT_REPAIRABLE

Preferred Availability

true

Quick Turnaround

false

Dimension Height

6.35

Lead Time

Dimension Width

13.97

Dimension Length

15.24

Stock Status

STOCKED

Weight Unit
