The Allen Bradley 1606-XLS120EA is a 120W switched mode power supply with adjustable secondary voltage, active PFC, and robust design for industrial use.
Product Model1606-XLS120EA
Product ID105743
Stock on Request
Last updated: 8/29/2026
Key Features
1
Feature1. High Efficiency and Reliability The 1606-XLS120EA boasts an efficiency of 92.7% typical, ensuring minimal power losses and maximum reliability in demanding industrial environments.
2
Feature2. Adjustable Secondary Voltage This power supply offers adjustable secondary voltage, allowing for flexibility in meeting various application requirements.
3
Feature3. Active Power Factor Correction (PFC) Equipped with active PFC, the 1606-XLS120EA minimizes harmonic distortion and ensures a stable power supply, reducing the risk of equipment damage.
4
Feature4. Robust Design for Harsh Environments Designed to withstand rigorous industrial conditions, this power supply features a durable construction and operates within a wide temperature range (-25°C to +40°C).
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Nominal value output voltage 1
24 V
Secondary voltage adjustable
Yes
Power output
120 W
Voltage type of supply voltage
AC/DC
Rated supply voltage at DC
110 V
Derating
3 w/°c
5
Feature5. Compliance with Industrial Standards The 1606-XLS120EA meets various industrial standards, including Class 1 Division 2 and semi-F47, making it suitable for use in hazardous locations and marine environments.
DC OK relay contact
Yes
Input inrush current limiter
Active
Output voltage
24...28V DC
Power factor
0.91 typical
External input fuse, min
B-6 A or C-3 A
Sub group
Performance family
Input voltage
100...240V @ AC, 47...63 Hz
Special feature
Active PFC, Class 1 division 2, semi F47, 9) ABS/GL/RINA (marine)
Output voltage stabilized
Yes
Rail mounting possible
Yes
Stabilized
Yes
Height
124 mm
Depth
117 mm
Direct mounting possible
No
Width
40 mm
Degree of protection (IP)
IP20
Type of electric connection
Spring clA connection
Special functions
Atex
Wall mounting possible
Yes
Degree of protection (NEMA)
Other
Ripple and noise, max
50 mV
Operating temperature
-25 °C
Non-operating temperature range
-40 to 85 °C
Repairable
NOT_REPAIRABLE
Preferred Availability
false
Quick Turnaround
false
Dimension Height
6.299
Lead Time
87
Dimension Width
14.605
Dimension Length
15.697
Stock Status
NON_STOCKED
Weight
0.723
Weight Unit
KG
Dimension Unit
CM
