XT2S 160 Ekip Dip LS/I In=160A 4pFF InN=100%

Name: XT2S 160 Ekip Dip LS/I In=160A 4pFF InN=100%
Brand: ABB
SKU: XT2S 160 Ekip Dip LS/I In=160A 4pFF InN=100%

The ABB XT2S 160 Ekip Dip LS/I 160A 4PFF circuit breaker is a high-performance, fixed-mount device designed for industrial applications. It features a current rating of 160A, 4 poles, and solid-state release for reliable operation.

Product ModelXT2S 160 Ekip Dip LS/I In=160A 4pFF InN=100%

Material Number1SDA067838R1

Product ID87571

Stock on Request

Last updated: 9/5/2026

Quantity

Key Features

1
1. High Current RatingThe XT2S 160 Ekip Dip LS/I has a current rating of 160A, making it suitable for demanding industrial applications.
2
2. Solid-State ReleaseThe circuit breaker features a solid-state release mechanism, ensuring fast and reliable operation in case of short circuits.
3
3. Front TerminalsThe device comes with front terminals, providing easy access for connections and reducing installation time.
4
4. Four Poles ConfigurationThe 4-pole configuration allows for versatile use in various electrical systems, including those requiring neutral connection.
5

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Environmental Information

9AKK108467A6707

Product Net Width

120 mm

Product Net Height

130 mm

Product Net Depth / Length

82.5 mm

Product Net Weight

1.6 kg

Circuit Breaker Type to be Associated

Power Distribution

5. Compliance with EU DirectivesThe product adheres to EU Directive 2011/65/EU and Amendment 2015/863, ensuring compliance with environmental regulations.

Product Main Type

SACE Tmax XT

Product Name

Moulded Case Circuit Breaker

Product Type

Automatic Circuit Breaker

Version

CAD Dimensional Drawing

1SDH002230A1002

Connecting Capacity Main Circuit

Busbar 32.5..100 mmÂ²

Current Type

Electrical Durability

120 cycles per hour 8000 cycle

Mechanical Durability

240 cycles per hour 25000 cycle

Number of Poles

Opening Time

CB with SOR 15 ms CB with UVR 15 ms

Order Multiple

1 piece

Power Loss

at Rated Operating Conditions per Pole 10.8 W

Rated Current (In)

160 A

Rated Frequency (f)

50 / 60 Hz

Rated Impulse Withstand Voltage (Uimp)

8 kV

Rated Insulation Voltage (Ui)

1000 V

Rated Operational Voltage

690 V AC

Rated Service Short-Circuit Breaking Capacity (Ics)

(220 V AC) 85 kA (230 V AC) 85 kA (240 V AC) 85 kA (380 V AC) 50 kA (415 V AC) 50 kA (440 V AC) 50 kA (500 V AC) 36 kA (525 V AC) 25 kA (690 V AC) 12 kA

Rated Ultimate Short-Circuit Breaking Capacity (Icu)

(220 V AC) 85 kA (230 V AC) 85 kA (240 V AC) 85 kA (380 V AC) 50 kA (415 V AC) 50 kA (440 V AC) 50 kA (500 V AC) 36 kA (525 V AC) 25 kA (690 V AC) 12 kA

Rated Uninterrupted Current (Iu)

160 A

Rated Voltage (Ur)

690 V

Recommended Screw Driver

Main Circuit M6

Release

Ekip Dip LS/I

Release Type

Short-Circuit Performance Level

Standards

IEC60947-2

Sub-type

XT2

Terminal Connection Type

Front

Terminal Type

Bolt

Tightening Torque

6 NÂ·m

ETIM 8

EC000228 - Power circuit-breaker for trafo/generator/installation protection

ETIM 9

EC000228 - Power circuit-breaker for trafo/generator/installation protection

Object Classification Code

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm)

eClass

V11.1 : 27370409

Manufacturer ID

1SDA067838R1
