2624-1308
WAGO 2624-1308 PCB terminal block with 4 mm² cross-section, 7.5 mm pin spacing, and 8 poles. Uses push-in CAGE CLAMP® technology.
Product Model2624-1308
Product ID50152
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureHigh-quality push-in CAGE CLAMP® technology for easy and reliable connections
- 2FeatureSuitable for both solid and fine-stranded conductors (0.2 … 6 mm² / 24 … 10 AWG)
- 3Feature8-pole design for multiple connections in a compact space
- 4Feature7.5 mm pin spacing for efficient board layout
- 5FeatureDurable and long-lasting construction
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
8
Total number of potentials
8
Number of connection types
1
Number of levels
1
Pin spacing
7.5 mm / 0.295 inches
