2606-1115/020-000
15-pole PCB terminal block with lever actuation and Push-in CAGE CLAMP®. Tool-free operation for solid and ferruled conductors.
Product Model2606-1115/020-000
Product ID50096
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureTool-free operation with lever actuation for easy conductor insertion and removal.
- 2FeaturePush-in CAGE CLAMP® technology for secure connections of solid and ferruled conductors.
- 3FeatureRated for up to 41 A (IEC) and 31 A (UL/CSA), with a rated voltage of 1000 V (IEC) and 600 V (UL/CSA).
- 4FeatureDurable construction with electrolytic copper contacts and polyamide insulation.
- 5FeatureCompliant with CSA and UL 1059 approvals for reliable performance in various applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
15
Total number of potentials
15
Number of connection types
1
Number of levels
1
Pin spacing
7.5 mm / 0.295 inches
