2626-1102/020-004
PCB terminal block with 6 mm², 2-pole, push-in CAGE CLAMP®, and CSA, UL 1059 approvals.
Product Model2626-1102/020-004
Product ID49856
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureHigh-quality push-in CAGE CLAMP® connection technology for secure and easy wiring.
- 2FeatureRated for up to 41 A and suitable for solid conductors from 0.2 to 10 mm².
- 3FeatureCompliant with CSA and UL 1059 standards for safety and reliability.
- 4FeatureCompact design with dimensions of 17.85 mm x 24.3 mm x 28 mm.
- 5FeatureDurable construction with electrolytic copper contacts and polyamide insulation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
2
Total number of potentials
2
Number of connection types
1
Number of levels
1
Pin spacing
7.5 mm / 0.295 inches
