2616-3102/010-000
PCB terminal block with lever, Push-in CAGE CLAMP, 2-pole, 10 mm pin spacing, and top entry for reliable connections.
Product Model2616-3102/010-000
Product ID48354
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureEasy and tool-free operation with Push-in CAGE CLAMP technology
- 2FeatureHigh reliability and secure connections
- 3FeatureCompatible with a range of conductor sizes (0.2 … 16 mm² / 24 … 4 AWG)
- 4FeatureDurable construction with Polyamide (PA66) housing and Chrome-nickel spring steel clamping springs
- 5FeatureMeets various international standards (e.g., IEC/EN 60664-1, UL 1059, CSA)
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
2
Total number of potentials
2
Number of connection types
1
Number of levels
1
Pin spacing
10 mm / 0.394 inches
