252-909
WAGO 252-909 is a 9-pole PCB mount header with 3.5mm pin spacing, suitable for reliable board-to-board connections.
Product Model252-909
Product ID48123
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureReliable board-to-board connections with 9 poles
- 2FeaturePCB mount design for easy integration
- 3Feature3.5mm pin spacing for compact applications
- 4FeatureCopper alloy clamping spring for secure contacts
- 5FeatureBlack color for easy identification
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Number of levels
1
Pin spacing
3.5 mm / 0.138 inches
Solder pin length
3.5mm
Solder pin diameter
1mm
Drilled hole diameter with tolerance
1.2(+0.05)mm
Suitable
Pin spacing: 3.5 mm / 0.138 inch
