250-417
17-pole PCB terminal block with 2.5 mm pin spacing, CAGE CLAMP® technology, and compatible with solid and fine-stranded conductors.
Product Model250-417
Product ID47752
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureCompact design with 2.5 mm pin spacing for efficient PCB layout.
- 2FeatureCAGE CLAMP® connection technology for easy and secure conductor insertion.
- 3FeatureCompatible with both solid and fine-stranded conductors (0.08–0.5 mm²).
- 4FeatureRated for up to 300 V and 15 A, meeting UL and CSA standards.
- 5FeatureDurable construction with Polyamide 6.6 insulation and chrome nickel spring steel clamping springs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
17
Total number of potentials
17
Number of connection types
1
Number of levels
1
Pin spacing
2.5 mm / 0.098 inches
