2616-3104/010-000
PCB terminal block with lever termination, suitable for 16 mm² conductors, 4-pole, and features Push-in CAGE CLAMP® technology.
Product Model2616-3104/010-000
Product ID45791
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureTool-free intuitive operation with Push-in CAGE CLAMP® and lever termination
- 2FeatureHigh current capacity and voltage ratings up to 1000 V
- 3FeatureMaximum wiring flexibility with side entry or top entry versions
- 4FeatureSecure and maintenance-free connections for all conductor types
- 5FeatureCompliant with UL94 V0 flammability class and rated for up to 120 ⁰C operating temperature
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
4
Total number of potentials
4
Number of connection types
1
Number of levels
1
Pin spacing
10 mm / 0.394 inches
