2604-1101/000-023
PCB terminal block with push-in CAGE CLAMP and operating lever. Suitable for AWG 24-12 wires and 5 mm pin spacing.
Product Model2604-1101/000-023
Product ID44461
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureEasy to install with push-in CAGE CLAMP
- 2FeatureOperating lever for secure connection
- 3FeatureSuitable for AWG 24-12 wires
- 4Feature5 mm pin spacing for precise connections
- 5FeatureScrewless - Spring Cage, Tension Clamp termination
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Note
The inherent stability of a single-pole PCB terminal block is less than that of a multi-pole terminal strip. The customer must therefore ensure that these terminal blocks are protected against excessive mechanical stress (e.g., torsional or bending stress), both when connecting the conductor and during subsequent use, for example by providing additional support, shortly holding the connected conductor and appropriate actuation instructions.
Variants:
Other pole numbers
Clamping units
1
Total number of potentials
1
Number of connection types
1
