2626-1352
PCB terminal block; 6 mm; Pin spacing 12.5 mm; 2-pole; Push-in CAGE CLAMP; green.
Product Model2626-1352
Product ID40034
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureIdeal for panel feedthrough applications via operation parallel to conductor entry.
- 2FeaturePush-in termination of solid and ferruled conductors.
- 3FeatureTesting can be performed both parallel and perpendicular to conductor entry.
- 4FeatureRated current up to 48 A and rated voltage up to 1000 V.
- 5FeatureCompliant with IEC/EN 60664-1 and UL 1059 standards.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
2
Total number of potentials
2
Number of connection types
1
Number of levels
1
Pin spacing
12.5 mm / 0.492 inches
