2626-1109/020-000
PCB terminal block with 6 mm² conductor size, 7.5 mm pin spacing, and 9 poles. Ideal for panel feedthrough applications.
Product Model2626-1109/020-000
Product ID40030
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeaturePush-in CAGE CLAMP connection technology for easy and secure conductor termination
- 2FeatureSuitable for solid and fine-stranded conductors (0.2 … 10 mm² / 24 … 8 AWG)
- 3FeatureIdeal for panel feedthrough applications
- 4FeatureRoHS compliant for environmental sustainability
- 5FeatureCompact design with 7.5 mm pin spacing and 9 poles
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
9
Total number of potentials
9
Number of connection types
1
Number of levels
1
Pin spacing
7.5 mm / 0.295 inches
