257-516
A 16-pole PCB terminal block with spring-loaded terminals, suitable for wire to board connections.
Product Model257-516
Product ID39876
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureHigh-quality spring-loaded terminals for reliable connections.
- 2Feature16 poles for multiple wire connections.
- 3FeatureCompatible with 2.5 mm² wire cross section.
- 4Feature7.5/7.62 mm pin spacing for standard PCB layouts.
- 5FeatureNominal voltage rating of 630V for robust performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
16
Total number of potentials
16
Number of connection types
1
Number of levels
1
Pin spacing
7.5/7.62 mm / 0.295/0.3 inches
