2626-3102/020-005
2-pole PCB terminal block with 7.5 mm pin spacing, Push-in CAGE CLAMP®, and 48 A rated current.
Product Model2626-3102/020-005
Product ID39152
Stock on Request
Last updated: 8/29/2026Key Features
- 1FeatureIdeal for panel feedthrough applications with operation parallel to conductor entry.
- 2FeatureSupports solid and ferruled conductors with easy push-in termination.
- 3FeatureHigh rated voltage and surge voltage capabilities (up to 1000 V and 8 kV).
- 4FeatureCompact design with dimensions of 16.8 mm x 28.2 mm x 18.5 mm.
- 5FeatureDurable construction with Polyamide (PA66) insulation and chrome nickel spring steel clamping springs.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
Specifications may be subject to change without notice
Parameter
Value
Parameter
Value
Variants:
Other pole numbers
Clamping units
2
Total number of potentials
2
Number of connection types
1
Number of levels
1
Pin spacing
7.5 mm / 0.295 inches
