ZB5AL9412

Name: ZB5AL9412
Brand: Schneider
SKU: ZB5AL9412

Product ModelZB5AL9412

Product ID26092

Stock on Request

Last updated: 9/5/2026

Quantity

Key Features

1
Feature-

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

Specifications may be subject to change without notice

Parameter

Value

Parameter

Value

Range of Product

Harmony XB5

Product or Component Type

Head for double-headed push-button

Device short name

ZB5

Bezel material

Plastic

Mounting diameter

0.9 in (22 mm)

Sale per indivisible quantity

Shape of signaling unit head

Type of operator

spring return

Operator profile

White flush, I black)Black projecting, O white)

Operators description

White ''I'' - black ''O''

CAD overall width

1.2 in (30 mm)

CAD overall height

2.0 in (50 mm)

CAD overall depth

1.4 in (35 mm)

Net Weight

0.057 lb(US) (0.026 kg)

Colour of marking

White marking when green, red or black capsBlack marking when white caps

Mechanical durability

1000000 cycles

Protective treatment

Ambient Air Temperature for Storage

-40...158 °F (-40...70 °C)

Ambient Air Temperature for Operation

-13...158 °F (-25...70 °C)

Electrical shock protection class

Class II IEC 60536

IP degree of protection

IP66 IEC 60529

NEMA degree of protection

NEMA 13NEMA 4X

Resistance to high pressure washer

1015.3 psi (7000000 Pa) 131 °F (55 °C) 0.1 m

IK degree of protection

IK03 conforming to IEC 50102

Standards

EN/IEC 60947-5-4EN/IEC 60947-1CSA C22.2 No 14UL 508EN/IEC 60947-5-1JIS C8201-5-1JIS C8201-1

Product Certifications

GLLROS (Lloyds register of shipping)BVUL ListedDNVCSA

Vibration resistance

5 gn 2...500 Hz)IEC 60068-2-6

Shock resistance

30 gn 18 ms) half sine wave acceleration IEC 60068-2-2750 gn 11 ms) half sine wave acceleration IEC 60068-2-27
